01What AprVisual is — and the wall we hit專案定位 —— 以及我們撞上的牆

AprVisual started from one goal: take Visual6502-style transistor netlists of the NES CPU (2A03) and PPU (2C02) and simulate them exactly at the switch level, while pushing that simulation as close to real time as software possibly can. Pure netlist simulation is a fundamentally heavy thing — the gap to real silicon speed is on the order of hundreds of times, and that gap is essentially algorithmic, not a coding detail.

AprVisual 從一個目標出發:把 NES CPU(2A03)與 PPU(2C02)的 Visual6502 風格電晶體網表,在開關級(switch-level)精確模擬,並把這個模擬盡量推到接近實機速度。純 netlist 模擬本質上非常吃資源 —— 離真實矽晶速度的鴻溝是數百倍等級,而且這個鴻溝是演算法層面的,不是寫法細節。

So the original blueprint was an automated pipeline (fully programmatic, no hand-tuning per chip) that lifts the netlist into higher-level abstractions for speed. Four stages:

所以原本的藍圖是一條自動化流程(全程程式化、不靠逐晶片人工調整),把 netlist 往上抽象化以換取效率。共四個階段:

The counter-intuitive part反直覺的地方

When you ask an AI — or most software engineers — how to speed this up, the answer is almost always the same: build an IR, do codegen, or throw it on a GPU. We actually built and verified those paths. And we found problems nobody mentioned up front:

當你問 AI —— 或多數軟體工程師 —— 怎麼加速,答案幾乎一致:做 IR、做 codegen、丟 GPU。我們真的把這些路徑實作並驗證了,結果發現一堆當初沒人提到的問題:

• After IR + codegen, the generated code bloats massively. We can automatically extract the netlist into logic gates — it works, in theory and in practice — but the codebase explodes and it runs worse, sometimes slower than just simulating the netlist directly.
• 產生 IR + codegen 之後,程式碼嚴重膨脹。我們確實能自動把 netlist 抽取成邏輯閘 —— 理論與實作都成立 —— 但 codebase 爆炸,而且執行得更糟,有時甚至比直接算 netlist 還慢。
• Information loss, especially around timing and correctness verification, makes the abstracted model hard to trust against the golden switch-level model.
• 抽象化會有資訊喪失問題,尤其是 timing 與正確性驗證,讓抽象後的模型難以對齊開關級 golden model。
• We even auto-generated hardware description languages (Verilog/HLSL) — but the whole point is to solve this in software, not to hand the performance problem to hardware.
• 我們甚至自動產生了硬體描述語言(Verilog/HLSL)—— 但本專案的重點是用軟體解決,不是把效能問題丟給硬體。
• Going further (abstracting gates into components or a behavioral layer) inevitably needs manual intervention and contradicts the project's whole intent: a real, solid hardware simulation. Keep abstracting and you've lost the point.
• 再往上抽象(把邏輯閘變成元件或行為層)勢必要人工介入,而且和專案初衷衝突:我們要的是真實紮實的硬體模擬。一直抽象下去就失去意義了。

Current direction: push S1 — the pure switch-level engine — to its absolute limit. The IR/codegen path is parked, not deleted; it's a verified dead-end for the performance goal, not for correctness.目前方向:把 S1 —— 純開關級引擎 —— 推到極致。IR/codegen 路徑是擱置、不是刪除;它對效能目標是已驗證的死路,但對正確性不是。

So what's actually new here?那這個專案到底新在哪?

The building blocks are classic: switch-level resolution (Bryant's model), event-driven vs levelized/oblivious simulation, "lowering" (constant-folding, dead-gate elimination, structural reduction), and "fast-path" common-case specialization are all well-studied — we invented none of them. But the work is not all one thing. Measured against decades of prior art, our changes fall into three honest tiers, and we label each as what it is — not all engineering, and not all novel either.

基礎元件都是經典的:開關級解析(Bryant 模型)、event-driven 對 levelized/oblivious 模擬、"lowering"(常數摺疊、死閘消除、結構化簡)、"fast-path" 常見情況特化,全是被充分研究過的點子 —— 我們沒發明其中任何一個。但這個專案的工作並非全屬同一層。對照數十年的既有文獻,我們的改動落在三個誠實的層級,而我們據實標示每一項是哪一種 —— 不是全部都只是工程,也不是全部都新。

Engineering (no novelty claimed) — the unmanaged structure-of-arrays layout, the double-buffered wave queues, the static singleton fast path, conjunct reordering, the supply-skip fold: competent implementation of standard ideas. Variants (a known technique with a specific, bit-exact twist) — the dynamic-singleton early-out (R-1) and the two-node pair path (B1), i.e. runtime cardinality specialization; the same-state pre-queue prune (P-1); and the class-major range-prune, a load-time inspector–executor data reorg. Original, to our knowledge — (a) the capacitance-dominance un-taint (P-3/P-4): a proof that a node which can never win the floating-charge tie-break can never change a resolved value, used to delete provably-null events safely; and (b) the self-captured first-touch relayout and its "order, not density" finding — the layout that actually pays is the one matching the pruned cascade's real access order, not the one with the fewest cache misses.

工程實作(不主張新穎)—— 非託管 SoA 佈局、雙緩衝波佇列、靜態 singleton fast-path、合取項重排、supply-skip 摺疊:把標準點子做紮實。變體(已知技術帶上特定、且位元精確的轉折)—— 動態 singleton 早退(R-1)與兩節點 pair path(B1),即執行期基數特化;同態入列前剪枝(P-1);以及 class-major 區間剪枝,一種載入期的 inspector–executor 資料重排。就我們所知為獨立貢獻——(a)電容支配解除汙染(P-3/P-4):證明「永遠贏不了浮接電荷 tie-break 的節點,永遠改變不了已解析的值」,用來安全地刪除可證明為空的事件;(b)自我捕捉初次觸碰重佈局及其「順序,不是密度」發現 —— 真正有用的佈局,是吻合已剪枝級聯實際存取順序的那個,而不是 cache miss 最少的那個。

What ties the three tiers together is the measurement discipline. Every change was validated on a real, full NES netlist — cross-checked on two independent engines (C# + Rust, bit-identical) and measured change by change — because most "obviously better" ideas lost on real hardware. R-1 is the cleanest example: by measuring rather than assuming, we found ~51% of all node re-evaluations are dynamic singletons, half the work avoidable — breaking a ceiling we (and our own earlier analysis) had already written up as "reached". The few ideas that survived, the honest tier label on each, and the catalogue of why the rest failed are the real contribution. Full breakdown: the prior-art comparison.把三個層級綁在一起的,是量測紀律。每一項改動都在一顆真實、完整的 NES netlist 上驗證 —— 兩個獨立引擎(C# + Rust,位元相同)交叉驗證、逐項實測 —— 因為多數「明明更好」的點子在真實硬體上都輸了。R-1 是最清楚的例子:靠實測而非假設,我們發現約 51% 的節點重算其實是動態 singleton、一半工作可省 —— 打破了我們(及自己先前分析)早已寫成「已到頂」的天花板。少數活下來的點子、每一項誠實的層級標示、以及「其餘為何失敗」的清單,才是真正的貢獻。完整對照:先前工作對照。

01·5What actually runs as transistors實際吃網表的部分 & 總規模

Staying honest about fidelity matters, so here's exactly what is simulated as a real transistor netlist versus a software behavioral model. Every NES internal logic chip runs 100% transistor netlist — the CPU, the PPU, all four board TTL chips, and both controllers. Only memory cell arrays, the master oscillator, and the video output are behavioral.

對「模擬到多真」保持誠實很重要,所以這裡明確列出哪些是真電晶體網表、哪些是軟體行為模型。所有 NES 內部邏輯晶片 100% 跑電晶體網表 —— CPU、PPU、四顆主機板 TTL、兩個手把。只有記憶體的儲存陣列、主振盪器、影像輸出是行為模型。

• The PPU and CPU alone are ~98% of all transistors; every TTL chip, controller, CIC and memory control-pin together is under 2%.
• 光是 PPU + CPU 就佔 ~98%;所有 TTL、手把、CIC、記憶體控制腳加起來不到 2%。
• Memory cell arrays (2 KB ×2 RAM/VRAM, 32 KB PRG, 8 KB CHR, optional 8 KB work RAM) are not counted — they're behavioral byte arrays. Simulating them as real 6T cells would add hundreds of thousands of transistors.
• 記憶體的儲存陣列(2 KB×2 RAM/VRAM、32 KB PRG、8 KB CHR、選用的 8 KB 工作 RAM)不計入 —— 它們是行為 byte 陣列。若真用 6T cell 模擬會多出數十萬顆電晶體。
• CIC is a 1-transistor reset-inverter stub, not a real region-lockout chip — NROM doesn't need lockout, so its 4-bit MCU was never modelled.
• CIC 只是 1 顆電晶體的 reset 反相殘樁,不是真的鎖區晶片 —— NROM 不需要鎖區,所以它的 4-bit MCU 從沒被模擬。
• After S1.5 lowering (merge always-on shorts, drop dead transistors, dedup), the engine actually simulates 26,775 transistors over 14,723 nodes — that's the real per-half-cycle workload.
• 經 S1.5 lowering(合併永遠導通短路、去死電晶體、dedup)後,引擎實際模擬的是 26,775 顆電晶體、14,723 個節點 —— 這才是每半週期真正的工作量。

Could this be smaller — a future speed-up? Possibly. Fewer nodes means smaller hot arrays and fewer that can ever go dirty, so shrinking the netlist itself is a candidate breakthrough. But the easy, safe cuts are already taken (the lowering above). Going deeper — folding constant / supply-tied nodes, collapsing logic-equivalent sub-networks — runs straight into the correctness traps that sank earlier attempts: cross-coupled latches with two stable states (which made prune-merge render a black screen) and the floating-capacitance tie-break (which "dead-end skip" broke). So it's a real but delicate avenue — any further reduction must be proven per-node equivalent and verified against a PPU visual frame, not just a CPU checksum.這還能更小嗎 —— 日後的速度突破口?有可能。節點少代表熱陣列更小、能變髒的節點更少,所以把 netlist 本身縮小是個候選突破點。但容易又安全的縮減已經撿光了(上面的 lowering)。再往下 —— 折疊常數 / 接電源的節點、收合邏輯等價子網路 —— 會直接撞上葬送先前嘗試的正確性陷阱:有兩個穩態的 cross-coupled latch(就是讓 prune-merge 渲染黑屏的元兇),以及 floating 電容 tie-break(「dead-end skip」踩的雷)。所以這是真實但細膩的方向 —— 任何進一步縮減都必須證明逐節點等價,並且用 PPU 畫面實圖驗證,而不只是 CPU checksum。

02What worked, what didn't — the interesting part過程心得 —— 有趣的部分

S1's base is an equivalent reimplementation of large parts of MetalNES — specifically its wire_compute group-resolution core, which is itself an optimized port of Visual6502's chipsim. On top of that foundation we ran a long campaign of optimization strategies. They split into two layers, and both are full of results that contradict intuition.

S1 的基礎是大量等價重寫 MetalNES —— 特別是它的 wire_compute group-resolution 核心(而那本身又是 Visual6502 chipsim 的最佳化移植)。在這個基礎上,我們跑了一長串優化策略,分成兩個層面,而兩邊都充滿反直覺的結果。

Negative cases (and why they fail)負面案例(以及為何失敗)

• ✗ Multi-threading / per-chip parallelism多執行緒 / 逐晶片平行 — ~15× slower. The simulation settles in tiny waves (the average connected group is ~1.4 nodes); per-wave work is far too small to amortize thread sync, and a barrier every half-cycle dominates. Visual NES's author reported the same lock-contention wall in 2017. 約 慢 15 倍。模擬是以極小的 wave 收斂(平均連通 group 只有 ~1.4 個節點),每個 wave 的工作量遠不足以攤平 thread 同步成本,而每半週期一個 barrier 就主導了一切。Visual NES 作者 2017 年也回報了同樣的 lock contention 牆。
• ✗ Bit-parallel / dense-scan BFS位元平行 / dense-scan BFS — bit-identical results but ~156× slower. Bit-parallel overhead is built for huge frontiers; it crushes the 99% of walks that touch one or two nodes. 結果位元完全相同,但慢約 156 倍。位元平行的成本是為龐大 frontier 設計的,卻被那 99% 只走一兩個節點的小 walk 壓垮。
• ✗ "Dead-end" / unobserved-node skip「死路」/ 未被觀察節點跳過 — broke correctness. A node with no fan-out gates still flows its state into any group it's pulled into — "no observer" was an illusion. 弄壞正確性。一個沒有 fan-out 的節點,只要被拉進某個 group,它的狀態仍會流進去 ——「沒有觀察者」是錯覺。
• ✗ Fancy data structures (hashset, presence arrays, counters)花俏資料結構(hashset、presence array、計數器) — net-negative, matching Visual NES's findings. Maintaining a per-node supply-counter cost −6% because the write path runs ~10× more often than the read it was meant to speed up. 淨負效益,與 Visual NES 的發現一致。維護每節點的 supply 計數器代價 −6%,因為寫入路徑比它想加速的讀取路徑多跑約 10 倍。
• ✗ Levelized scheduling分層排程(levelized scheduling) — ordering each settle wave by topological level to cut redundant re-evaluations. It did reduce the work slightly (dirty-set −1.3%, fewer glitches) — but the counting-sort to maintain that order cost −15% hc/s: net negative. Root cause: ~94.5% of the netlist is one giant pass-transistor-coupled SCC, so there's no useful static topological order to exploit. (The structure was the wall, not the idea.) 把每道 settle 波依拓樸層級排序以減少重複評估。它確實稍微降低了運算量(dirty-set −1.3%、突波變少)—— 但維持順序的 counting-sort 代價是 −15% hc/s:淨負。根因:這顆 netlist 約 94.5% 是同一個 pass-transistor 耦合的大 SCC,沒有有效的靜態拓樸序可利用。(牆是結構,不是這個點子本身。)
• ✗ "Oblivious" full-sweep evaluation「oblivious」全掃描評估 — dropping the dirty-set and recomputing every node each half-cycle. Measured ~121× slower: it re-evaluates ~14,700 nodes (× several sweeps to a fixpoint) when only a few hundred actually changed. The same "recompute everything" cause is exactly why the batch AOT/codegen (~3–6×) and GPU (~10–18×) backends also lost to the event-driven interpreter. 丟掉 dirty-set,每半週期重算所有節點。實測 ~121× 慢:實際只有幾百個節點變動,它卻重算 ~14,700 個(再 ×數趟掃到 fixpoint)。同樣「全部重算」的根因,也正是批次 AOT/codegen(~3–6×)與 GPU(~10–18×)後端輸給事件驅動直譯器的原因。
• ✗ Generation-counter dedup世代計數器去重 — replacing "clear the visited flags" with a monotonic epoch counter to skip the clear. −3.9%: the wider counter and its periodic reset cost more than the per-call clear it removed. 把「清掉 visited 旗標」改成單調遞增的世代計數器以省下清除步驟。−3.9%:較寬的計數器加上它的週期性重置,比它省掉的每次清除還貴。

An important caveat: most of these failures are not flaws in the strategy itself — they're mismatches with the hardware it ran on. A method can be perfectly correct, even more elegant on paper, yet collapse the moment its instruction footprint (i-cache) or working set (d-cache) spills out of cache and starts thrashing. So what failed wasn't the idea — it's that the idea didn't fit this CPU's operating envelope. The flip side is the interesting part: as hardware advances — larger caches, more memory bandwidth — some of these more aggressive strategies could turn out to be exactly the right fit.一個重要的但書:這些策略的失敗,多半不是策略本身有問題,而是它和所跑的硬體不合拍。一個方法可以完全正確、甚至在紙上更優雅,但只要它的指令足跡(i-cache)或工作集(d-cache)一溢出快取、開始顛簸(thrashing),就會崩潰。所以失敗的不是那個點子,而是它剛好不符合這顆 CPU 的使用情境。而反過來才是有意思的地方:哪天硬體更進步 —— 更大的快取、更高的記憶體頻寬 —— 這些較激進的策略,可能反而剛好適用。

Wins (what actually moved the needle)真正有效的

• ✓ Memory shrink記憶體縮減 — the biggest, most reliable lever. int → ushort/byte, hot/cold struct splitting (SoA), packing the hot per-node record to a quarter cache line. Keeping the working set in L1d matters more than any clever loop. 最大、最可靠的槓桿。int → ushort/byte、hot/cold 結構拆分(SoA)、把每節點的熱記錄壓到 1/4 cache line。把 working set 留在 L1d 比任何聰明的迴圈都重要。
• ✓ Unlocking the JIT inline cascade解鎖 JIT inline cascade — rewriting the recursive group walk as an iterative loop let the .NET JIT inline the whole chain (+~3% on C#). The exact opposite of helpful on Rust — LLVM already inlines the recursive form. 把遞迴的 group walk 改成 iterative loop,讓 .NET JIT 能 inline 整條鏈(C# +約 3%)。在 Rust 上卻完全相反 —— LLVM 本來就把遞迴形式 inline 得很好。
• ✓ Removing work from the hot loop把工作移出熱迴圈 — deferring a rarely-needed field read out of the per-visit path was +12% on C#; bounds-check elision was +12% on Rust. 把一個很少用到的欄位讀取延後、移出每次拜訪的路徑,C# +12%;Rust 移除 bounds check +12%。
• ✗→✓ A reversal: "prune-merge" failed, then won as P-1一次反轉:prune-merge 先失敗、後以 P-1 兌現 — skip re-settling when a merge can't change the result. The first try (2026-05-24, --prune-merge) blanked the PPU — it didn't exclude the chip's dynamic/storage cells — and the "fix" (a runtime group-id, re-stamped every walk) cost more than it saved: −4.4% C# / −6.7% Rust, abandoned as a dead-end. The same idea then shipped bit-exact and +11.85% C# / +11.36% Rust as P-1 — won by a cheap static pull-up mask (one byte, zero runtime bookkeeping) that excludes exactly those memory nodes. The win was never the idea; it was finding the cheapest correct form. (Two root causes — runtime cost + no memory-node exclusion — pointed straight at the fix; full story in the P-1 card & prunes write-up.) 在合併不會改變結果時,跳過重新 settle。第一次嘗試(2026-05-24,--prune-merge)讓 PPU 全黑 —— 它沒排除晶片的動態/記憶體 cell —— 而那個「修法」(執行期 group-id、每次走訪重新蓋章)成本蓋過省下的:C# −4.4% / Rust −6.7%,被當死路放棄。同一個想法後來以 P-1 bit-exact 兌現,C# +11.85% / Rust +11.36% —— 贏在便宜的靜態上拉 mask(一個 byte、零執行期簿記),正好排除那些記憶體節點。贏的從來不是想法,而是找到最便宜又正確的形式。(兩個真因 —— 執行期成本 + 沒排記憶體節點 —— 直接指向正解;完整故事見 P-1 卡片與 剪枝專文。)
• ✗→✓ A second reversal: locality renumbering (RCM) failed, then won as range-prune第二次反轉:區域性重編號(RCM)先失敗、後以範圍剪枝兌現 — As an RCM cache-locality play (2026-05), renumbering measured ~1.04× boot / ~0.98× steady — nothing (the hot set was already cache-resident; even a later near-perfect co-activity packing, −45% line footprint, still moved nothing). The verdict on locality stands. But in June the same permutation machinery was re-aimed at a different objective: sort nodes class-major so each prune class is one contiguous id block, and the hottest loop's PruneMask[c] lookups — dependent loads sitting on the carried enqueue chain — become register compares. +3.56% C# / +2.90% Rust, bit-exact, on by default — the biggest win since P-1. Same tool, different question: dead ends are indexed by objective, not by tool. (Full story: the dead end that came back & the range-prune card.) 作為 RCM cache 區域性方案(2026-05),重編號實測開機 ~1.04× / 穩態 ~0.98× —— 等於沒用(熱集早已常駐快取;後來連近乎完美的共活性打包 —— line 足跡 −45% —— 也動不了什麼)。對區域性的判決依然成立。但六月,同一套排列機器被重新瞄準另一個目標:把節點以類別為主鍵排序,讓每個剪枝類別佔一段連續 ID 區間,於是最熱迴圈的 PruneMask[c] 查表 —— 坐在被攜帶的入列鏈上的相依載入 —— 變成暫存器比較。C# +3.56% / Rust +2.90%、bit-exact、預設開啟 —— P-1 以來最大的勝利。同一把工具、不同的問題:死路的索引鍵是目標函數,不是工具。(完整故事:復活的死路與範圍剪枝卡片。)

02·7Major algorithm breakthroughs重大演算法突破

A short, curated list of the changes that produced the largest verified speedups — every one bit-identical to the reference model (same NodeStates checksum, confirmed pixel-for-pixel on a rendered PPU frame). The newest headlines — range-prune (the class-major renumber that turned a measured dead end into the biggest win since P-1, on both engines), P-1 (same-state turn-on prune, the first big win to land on both engines at once), M-1 (register-resident group walk + wide loads), S2-A (cache-conscious data layout) and R-1 (dynamic-singleton fast-path) — each broke a ceiling we'd already written up as "reached". The memory-layout techniques behind M-1 and S2-A get a dedicated walk-through in the cache & memory-layout tutorial.

這是一份精選短清單,列出帶來最大、且經驗證加速的改動 —— 每一項都與參考模型位元完全相同(NodeStates checksum 一致,並在實際 PPU 畫格上逐像素確認)。最新的頭條 —— 範圍剪枝(類別為主鍵重編號,把一條被實測判死的死路翻成 P-1 以來最大的勝利,雙引擎成立)、P-1(同態 turn-on 剪枝,第一個同時在兩個引擎都成立的大勝)、M-1(暫存器常駐 group walk + 寬讀取)、S2-A(cache 導向資料佈局)與 R-1(動態 singleton fast-path)—— 各自突破了我們先前已寫成「已到頂」的天花板。M-1 與 S2-A 背後的記憶體佈局技巧,在cache 與記憶體佈局教學裡有專門的逐步說明。

The other confirmed wins其他確認有效的勝利

• ✓ Pure-logic fast-path (static)純邏輯 fast-path(靜態) — O(1) resolve for the ~27% of nodes provably forming a singleton group; skips the BFS entirely. The foundation R-1 extends to the dynamic case. 對 ~27% 可證明為單節點 group 的節點做 O(1) 解析、完全跳過 BFS。R-1 正是把它延伸到動態情形。
• ✓ Hot-data shrink + SoA熱資料縮減 + SoA — byte/ushort fields, hot/cold split packed to a quarter cache line — the single biggest reliable lever (keep the working set in L1d). byte/ushort 欄位、hot/cold 拆到 ¼ cache line —— 最大、最可靠的單一槓桿(把 working set 留在 L1d)。
• ✓ Deferred capacitance read延後讀電容 — move a rarely-needed field read out of the per-visit path → +12% on C#. (Bounds-check elision did the same job on Rust, +12%.) 把很少用到的欄位讀取移出每次拜訪路徑 → C# +12%。(Rust 上由移除 bounds check 達成同樣效果,+12%。)
• ✓ S1.5 lowering pre-passS1.5 lowering 前置 — merge always-on shorts, drop dead transistors, dedup + dense compaction — once, before simulating. 合併永遠導通短路、移除死電晶體、dedup + 緻密重編號 —— 模擬前做一次。
• ✓ Branchless OR-all fast-path scan (C# only)無分支 OR-all fast-path 掃描(僅 C#) — +0.6% on C# by removing a per-gate branch; −3.2% on Rust, so kept C#-only — a clean example of the cross-engine divergence below. 移除每個 gate 的分支,C# +0.6%;Rust −3.2%,故只在 C# 採用 —— 下方「跨引擎反號」的乾淨例子。

Each entry is backed by per-change interleaved-paired A/B numbers and checksums in the repository's optimization notes. R-1 narrowed the gap to NES real-time from ~645× to ~550×, and the wins since — memory-layout, the P-1 same-state turn-on prune, and the P-2 → P-4 event-count prunes (which delete ~21% of all node re-evaluations) — took C# to ~393× — still far off, but the ceiling keeps moving. Run the benchmark on your own CPU and the version stamp (engine + git commit + date) is recorded with your result on the leaderboard.

每一項都有 repo 優化筆記裡逐項的 interleaved-paired A/B 數字與 checksum 佐證。R-1 把距 NES 即時的差距從 ~645× 縮到 ~550×,之後的優化 —— 記憶體佈局、P-1 同態 turn-on 剪枝、以及 P-2 → P-4 事件數剪枝(刪掉約 21% 的節點重算)—— 把 C# 推到 ~393× —— 依然很遠,但天花板持續在移動。在你自己的 CPU 上跑 benchmark,版本戳記(引擎 + git commit + 日期)會跟著你的結果記在排行榜上。

For readers from academia — term mapping: what we call "lowering" ≈ logic-synthesis constant-folding / dead-gate elimination / structural reduction; the "fast-path" (and its dynamic extension R-1) ≈ common-case specialization of event-driven simulation. The switch-level model itself is Bryant's; the simulation-strategy taxonomy (event-driven vs levelized vs oblivious) is textbook. We borrow the compiler / systems vocabulary — the equivalent EDA techniques are all classic.給學術背景的讀者 —— 術語對照:我們稱的 "lowering" ≈ 邏輯合成的 constant-folding / dead-gate elimination / 結構化簡;"fast-path"(及其動態延伸 R-1)≈ event-driven 模擬的 common-case 特化。開關級模型本身出自 Bryant;模擬策略分類(event-driven 對 levelized 對 oblivious)是教科書級。我們借用編譯器 / 系統的詞彙 —— 對應的 EDA 技術都是經典。

Read the full research landscape — is the algorithm ceiling reached? →看完整研究現況 —— 演算法天花板到了嗎? →

Why the "obvious" speedups (matrix / GPU / threads / codegen) don't work →為什麼「直覺加速」(矩陣 / GPU / 多執行緒 / codegen)都沒用 →

Why IR / codegen still hit the wall — the whole-NES profile data →為什麼 IR / codegen 仍撞牆 —— 整機 profile 數據 →

Study paper: when does automatic abstraction beat an event-driven switch-level sim? →研究論文:自動抽象化何時能贏過事件驅動開關級模擬? →

03Where it stands — and a call to help最終成果 —— 以及邀請

Real time was known to be out of reach from day one. But once the engine got fast enough, it crossed into being a genuinely useful, verifiable tool. The numbers below are our actual run on the dev machine (the screenshot at the bottom of this section), benchmarking 400,000 master half-cycles of full_palette (best of 30, pinned):

從第一天就知道 realtime 達不到。但引擎快到一個程度後,它就跨進「真正可用、可驗證的工具」這個門檻了。以下是我們在開發機上的實際跑分(本節下方的截圖),測試 full_palette 的 400,000 個 master half-cycle(20 次取最佳、已釘核心):

On this machine C# now renders a frame in ~5.0 s and Rust in ~5.7 s (both engines produce a bit-identical result — same checksum 0x794A43ABDF169ADA). The arc: the R-1 dynamic-singleton fast-path lifted both to ~78K; memory-layout wins took C# to ~91K / Rust ~83K; the same-state turn-on prune (P-1) added +11.85% / +11.36%; then a family of event-count prunes (P-2 → P-4) — skip re-evaluating a node when it provably can't change — added another +7.7% on C# / +10.0% on Rust (bit-exact, landed positive on both back-ends); a later profiled &&-clause reorder (lead with the most-often-false test) added +~1% more on C#, then folding the supply-skip into the prune mask (so the turn-off enqueue check is uniform — no special supply guard) added another +~1.5-2% on C#; then moving the build to .NET 11 (runtime/JIT only, bit-exact) added ~+1% more; then range-prune (2026-06-11) — a class-major auto-renumber that turns the prune-mask lookups into id range compares, the dead end that came back — added +3.6% C# / +2.9% Rust; the renumber's locality key became self-captured (2026-06-11) — the load warms the chip and records the TRUE first-touch order of the production cascade through a cold instrumented settle copy, no file, no flag, any ROM — adding +6.2% on C# (20/20 paired, → ~126.7K); and finally the B1 pair path (2026-06-12) — resolve a provably-two-node conducting group inline, skipping the whole group-walk machinery (size-2 groups are 77% of all walks) — added +7–9% on C# at boost (under ~1% at base clock — it deletes dependent-load chain links, so its share grows with frequency) and +14.5% on Rust (20/20 paired; its recursive group walk had been paying a call chain per pair); and finally the falling-writeback split (2026-06-18) — the turn-off fan-out walks a pre-filtered endpoint list built at load (ids below the prune boundary stripped), so the hot loop drops its per-endpoint range compare and iterates a shorter list — added +1.2% C# / +6.9% Rust (bit-exact; the Rust branchless walk had paid that compare on every endpoint, so it gained far more); and finally the turn-off dedupe + GndPwr fast-path (2026-06-20) — strip duplicate turn-off endpoints at load, plus special-case the dominant 1/2-GND-gate, 0-PWR inline shapes in RecalcNodeFast (read the packed GndPwr byte once, skip the PWR scan) — added ~+2.6% more (Pi5 @3.0G locked, 16-round interleaved-paired, bit-exact), reaching ~96.4K hc/s on the Pi5 @3.0G (now the authoritative bench; the Zen 2 desktop flagship ~142.4K C# / ~126.6K Rust (best of 30, cold-machine boost, pinned; leaderboard id 43, rank 1)). The prunes delete ~21% of all node re-evaluations at the source. Read how the prunes work → NES NTSC real-time still needs 42,954,552 hc/s, so C# is ~302× short; that remaining gap is exactly why outside ideas and faster machines are valuable.

在這台機器上,C# 現在算一張 frame 要 ~5.0 秒、Rust 要 ~5.7 秒(兩個引擎輸出位元完全相同 —— checksum 同為 0x794A43ABDF169ADA)。歷程:R-1 動態 singleton fast-path 把兩者拉到 ~78K;記憶體佈局優化把 C# 推到 ~91K / Rust ~83K;同態 turn-on 剪枝(P-1)加了 +11.85% / +11.36%;接著一組事件數剪枝(P-2 → P-4) —— 在節點可證明不會變時跳過重算 —— 又加了 C# +7.7% / Rust +10.0%(bit-exact,兩個後端都正);之後再依剖析把 && 條件重排(最常為 false 的判斷排最前)又加了 C# +~1%,接著把供電跳過折進剪枝遮罩(turn-off 入列檢查變得一致、不需特別的供電守衛)又加了 C# +~1.5-2%;接著把 build 換到 .NET 11(只是 runtime/JIT、bit-exact)再加 ~+1%;接著是範圍剪枝(2026-06-11)—— 類別為主鍵的自動重編號,把剪枝遮罩查表變成 ID 區間比較,那條復活的死路 —— 再加 C# +3.6% / Rust +2.9%;重編號的 locality 鍵改成自我捕捉(2026-06-11)—— 載入時先暖機、再用一份冷的儀器化 settle 拷貝記錄生產級串接的「真實首次彈出順序」,零檔案、零旗標、任何 ROM 通用 —— 再加 C# +6.2%(20/20 配對,→ ~126.7K);最後是 B1 成對路徑(2026-06-12)—— 可證明只有兩個節點的導通群組就地解析、跳過整套群組走訪機制(size-2 群組佔全部走訪的 77%)—— C# boost 下 +7~9%(基頻下不到 1% —— 它刪的是相依載入鏈節,佔比隨時脈升高而變大)、Rust +14.5%(20/20 配對;它的遞迴群組走訪本來每一對都在付一條呼叫鏈);最後是下降寫回拆分(2026-06-18)—— turn-off 扇出改走載入時預先過濾的端點清單(低於剪枝邊界的 id 已剔除),熱迴圈省掉每端點的範圍比較、清單也更短 —— 加了 C# +1.2% / Rust +6.9%(bit-exact;Rust 的 branchless 走訪本來每個端點都在付那個比較,所以賺更多);最後是 turn-off 去重 + GndPwr fast-path(2026-06-20)—— 載入時剔除 turn-off 重複端點,並在 RecalcNodeFast 特化最常見的 1/2-GND-gate、0-PWR inline 形狀(一次讀進打包的 GndPwr byte、跳過 PWR 掃描)—— 再加 約 +2.6%(Pi5 @3.0G 鎖頻、16 輪 interleaved-paired、bit-exact),在 Pi5 @3.0G 達 ~96.4K hc/s(現在的權威量測;Zen 2 桌機旗艦 ~142.4K C# / ~126.6K Rust(冷機 boost、30 取最佳、已釘核心;排行榜 id 43、第 1 名))。剪枝從源頭刪掉了約 21% 的節點重算。看剪枝怎麼運作 → NES NTSC 實機仍需每秒 42,954,552 個 hc,所以 C# 還差約 302 倍;這個剩下的差距,正是外部點子與更快機器有價值的原因。

03·5Hardware test-ROM validation — the report card硬體測試 ROM 驗證 —— 成績單

Once the engine was fast enough to be a tool, we pointed it at the standard NES accuracy batteries (blargg's test suites and friends): every NROM/CNROM NTSC ROM in the nes-test-roms collection — 147 tests — each judged once per simulated frame with no human watching: the blargg $6000 protocol, ROM-requested soft resets (the engine pulses the console's reset line mid-run), terminal screen text read straight out of the nametable, or an on-screen CRC. Frame budgets were calibrated by an instrumented copy of our behavioral emulator AprNes acting as a fast oracle, and the batch runs unattended on core-pinned parallel workers (longest tests first) — a full 147-ROM sweep completes in 6.2 h on 7 pinned cores.

引擎快到能當工具之後,我們把它對準了標準的 NES 精確度測試集(blargg 系列等): nes-test-roms 合集中所有 NROM/CNROM NTSC 的 ROM —— 共 147 個 —— 每個都以「每模擬幀判讀一次」的方式全自動判定:blargg $6000 協定、ROM 主動要求的軟重設 (引擎中途拉主機 reset 線)、直接從 nametable 讀出的終端畫面文字、或畫面 CRC。 幀數預算由改造版的行為層模擬器 AprNes 當快速 oracle 校準,批次在綁核的平行 worker 上無人值守跑完(最長的測試優先排程)—— 完整 147 顆 ROM 的全量回歸,在 7 顆綁定核心上約 6.2 小時跑完。

It started at 115/26 and closed at 146/1. That climb is the interesting half. Most of the FAILs were genuine gaps in our model — a same-half-cycle race a two-state engine must resolve, an unmodeled cross-die write delay, an OAM-DMA bus-hold detail — the physics of the two dies is real, but a few correct behaviors live outside what pure switch-level propagation of the CPU+PPU alone can express. For each, real hardware has a well-defined answer, so we supply that spec through a documented, test-mode behavioral shim and the test PASSES; every shim is test-mode only, and the engine's default benchmark path stays bit-identical with or without it. The single remaining FAIL is the opposite case: cpu_dummy_writes_oam literally declares that its prerequisite ("OAM reads must be reliable") holds on emulators but not on the real NES — and our pinned RP2C02G is exactly the PPU revision with the OAMADDR-write corruption bug, so a switch-level 2C02 whose OAM is physical DRAM cells fails it the way real G silicon does. Forcing a PASS there would move the simulation away from the machine we target, not closer.

計分從 115/26 一路走到 146/1,而這段爬升才是有趣的那一半。大多數 FAIL 其實是我們模型的缺口 —— 二值引擎只能解錯邊的同半週期賽跑、未建模的跨晶片寫入延遲、OAM-DMA 匯流排持值細節 —— 兩顆晶粒的物理是真的,但有少數正確行為,單靠 CPU+PPU 的開關級傳播根本表達不出來。 這些真機都有明確答案,所以我們用文件化的測試模式行為層 shim 把那份規格補上,測試就通過; 每個 shim 都只在測試模式作用,引擎預設的 benchmark 路徑掛不掛都逐位元相同。 唯一殘留的 FAIL 則是相反的情況:cpu_dummy_writes_oam 的說明自己寫著,其前置需求 (「OAM 讀取必須可靠」)在模擬器上成立、在真實 NES 上不成立 —— 而我們鎖定的 RP2C02G 正是帶有 OAMADDR 寫入損毀 bug 的那個 PPU 版次,所以 OAM 是物理 DRAM cell 的開關級 2C02 就像真 G 晶片一樣失敗。硬要它通過,反而讓模擬偏離我們鎖定的機器,而不是更近。

Open the full interactive report → — per-test screenshots, detection method, frame counts, per-test khc/s, and the exact hardware model (RP2A03G + RP2C02G netlists; what is transistor-level and what is behavioral). Deep-dive Q&A on the faithful deviation: EN · 繁中.

打開完整互動成績單 → —— 每個測試的截圖、判定方式、幀數、 per-test khc/s,以及精確的硬體模型說明(RP2A03G + RP2C02G netlist;哪些是電晶體級、哪些是行為層)。 忠實偏差的深入解說 Q&A: 繁中 · EN。

Next up: AccuracyCoin, unattended 下一戰:AccuracyCoin 無人值守

The blargg-era suites above are the settled campaign. The ongoing one is AccuracyCoin — 141 tests on one cartridge, written for the exact die revisions (RP2A03G + RP2C02G) our netlists model, and aggressive enough that it has been a stress test for the simulator itself: it has already exposed and killed a callback re-entrancy bug, an analog feedback loop with no digital fixed point, and a mis-wired mirroring pad. We forked it into an unattended build and are running it transistor by transistor.

上面 blargg 時代的測試集是已收官的戰役;進行中的是 AccuracyCoin —— 一張卡帶 141 個測試,鎖定的正是我們 netlist 模擬的那兩顆晶粒版本(RP2A03G + RP2C02G), 而且兇到變成模擬器本身的壓力測試:它已經逼出並殺掉一個 callback 重入 bug、 一條沒有數位固定點的類比回授迴路、和一個接錯的鏡像焊點。 我們把它 fork 成無人值守版,正在逐電晶體地跑。

Open the AccuracyCoin campaign report →打開 AccuracyCoin 戰役報告 → — the bug stories, the diagnostic toolbox, the current scorebug 戰記、診斷工具箱、目前戰況

04How it compares to other netlist NES / 6502 simulators與其他 netlist NES / 6502 模擬器的比較

Speed claims across these projects use different units (6502 clocks, chip steps, trace lines, master half-cycles), so this is not a clean apples-to-apples table — hardware era, tracing, feature completeness and frame definitions all differ. With that caveat, here's the public picture:

這些專案的速度說法單位不同(6502 clock、chip step、trace line、master half-cycle),所以這不是乾淨的同基準比較 —— 硬體年代、tracing、功能完整度、frame 定義都不一樣。帶著這個但書,以下是公開資料的全貌:

Takeaways幾個結論

• Full NES transistor-level software simulation publicly lands in the tens-of-seconds to minutes per frame range — never the FPS range of an ordinary emulator.
• 完整 NES 電晶體級軟體模擬,公開資料都落在每 frame 數十秒到數分鐘的等級 —— 從來不是一般模擬器的 FPS 等級。
• AprVisual's current numbers sit clearly above the public early figures for Visual NES and MetalNES — but note those are from a 2017 i5 (often with tracing) and 2022-era user reports, so it is not a fair head-to-head.
• AprVisual 目前的數字明顯高於 Visual NES 與 MetalNES 的公開早期數字 —— 但那些來自 2017 年的 i5(常帶 tracing)與 2022 年的使用者回報,所以不是公平的正面對決。
• Our experience matches Visual NES's exactly: the hot spot is the recursive group / connected-component search, and data shrink + cache + PGO beat fancier data structures. Independent projects converging on the same conclusion is a strong signal.
• 我們的經驗和 Visual NES 完全吻合:熱點都在遞迴的 group / connected-component 搜尋,而且縮資料 + cache + PGO 勝過更花俏的資料結構。兩個獨立專案得到同樣結論,是很強的訊號。
• perfect6502 shows even a single 6502 netlist, in highly-optimized C on a 2025 CPU, only hits ~1/30 real time — transistor-level exactness is just expensive.
• perfect6502 顯示:即使是單顆 6502 netlist、高度最佳化的 C、2025 CPU,也只有約 1/30 realtime —— 電晶體級的精確就是這麼貴。

Sources: Visual6502 & NESdev wiki, perfect6502 README, Visual NES README + author's 2017 nesdev threads, MetalNES README + press/HN reports. AprVisual figures are this machine's run (full_palette, 300k hc).來源:Visual6502 與 NESdev wiki、perfect6502 README、Visual NES README + 作者 2017 nesdev 討論串、MetalNES README + 媒體/HN 報導。AprVisual 數字為本機實測(full_palette、300k hc)。

Read the full comparison →閱讀完整比較深入頁 →

Per-project breakdowns, the unit caveats, frame-time derivations, and all sources.各專案逐一拆解、單位注意、frame-time 推算、完整來源。

📄 Papers & monograph📄 論文與專論

The full write-up of the project — the silicon-connectivity → logic translation/verification pipeline, the falsifiable single-core "real-time is unreachable" negative result, and the ablation — now open to read and download. By 黎映微 (Ying-Wei Li).這個專案的完整論述 —— 矽連線 → 邏輯的翻譯/驗證 pipeline、「單核即時不可達」的可否證負面結果、以及消融分析 —— 現在公開,可自由閱讀與下載。作者 黎映微 (Ying-Wei Li)。

It was originally prepared for journal submission, but with a demanding workload and no spare time for the back-and-forth of peer review, I decided against submitting and to simply share it openly instead — as a reference for anyone who would like to take the research further. Please note it has not been peer-reviewed.這份研究原本打算投稿期刊,但因工作繁忙、難以負擔審稿往返所需的時間與心力,最終決定不投稿,而是直接公開分享,提供給有興趣進一步研究的人參考。內容未經同儕審查,引用時敬請自行斟酌。

A further note: the paper reflects a mid-June 2026 snapshot. The engine has kept improving since — especially a line of work that cuts the computation at its source by exploiting the circuit's physics and mathematical structure (event-count prunes that prove a node can't change, inline resolution of two-node conducting groups, load-time gate-list classification, and more), giving additional speedups that are not yet written up in the paper. For the latest figures see the Results section above and the leaderboard.另須補充:本文是 2026 年 6 月中的快照。之後引擎仍持續改版與優化 —— 尤其是從源頭削減計算量的一系列方法,以電路的物理與數學特性為依據(例如可證明節點不會改變的事件數剪枝、雙節點導通群組的就地解析、載入期的閘列表分類等),效能因而又有提升;這些較新的成果尚未寫入文中。最新數據請參考上方成果區與排行榜。

⬇ Monograph — English (PDF)⬇ 專論 — 英文(PDF) ⬇ Monograph — 中文 (PDF)⬇ 專論 — 中文(PDF)

Journal form — 期刊版 —— arXiv EN · arXiv 中文 · IEEE EN · IEEE 中文
